Home > L Port Type Ball Valve
Ayten Tube Fittings, a trusted manufacturer and supplier based in Addis Ababa, Ethiopia, offers precision-engineered L Port Type Ball Valves designed for reliable and efficient fluid control. These valves feature an L-shaped flow passage that allows for diverting or mixing flow between two different ports with a simple quarter-turn operation. Built from high-quality materials, Ayten’s L Port Type Ball Valves deliver excellent durability, leak-proof performance, and smooth operation under high pressure. They are ideal for diverse applications in chemical, oil and gas, pharmaceutical, water treatment, and power generation industries requiring versatile and efficient flow direction control.
L Port Type Ball Valves are constructed from robust materials such as stainless steel, carbon steel, brass, or nickel alloys, chosen for their mechanical strength and corrosion resistance. The valves feature precision-machined components, ensuring high tensile and yield strength, smooth operation, and excellent sealing integrity. Designed to withstand high pressures and temperatures, they exhibit superior wear resistance and durability. The L-shaped ball passage enables flexible flow control between two ports, providing consistent performance, long service life, and easy maintenance in both industrial and utility piping systems.
| TYPE : | 3 way L-port Floating Ball Valve |
| Configuration : | L-port, Divertor Type, 2 seat Construction |
| PORT : | Full Bore |
| SIZE : | 15 mm to 200mm NB |
| Pressure Rating : |
ASME#150PN 20
ASME#300PN 50
|
| Temperature Range | 35 Deg C to 280 Deg C (Soft Seated) |
| Body Materials | Stainless Steel / Carbon Steel / Alloys |
| Design Standard | API 6D rev 23; ISO 17292 rev 2004 |
| End Flanges | ASME B16.5 2013 |
| Face to Face Dimension | ASME B16.10 Rev 2009 |
| Fire safe design | API-607 Rev 2010 |
| Testing | API 598 Rev 2009 |
| Sour Service | NACE MOR 0175 Rev 2009 |
| Documents | BS/EN 10204-3.1 REV 2004 |
At Ayten Tube Fittings, we are the largest supplier, manufacturer, and exporter of L Port Type Ball Valve in Addis Ababa, Ethiopia. Our advanced manufacturing facilities, strategically positioned in the Ethiopia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands
| SR.NO. | PART NAME | STAINLESS STEEL | CARBON STEEL | QTY |
|---|---|---|---|---|
| 1 | BODY | ASTM A351 CF8M | ASTM A216 WCB | 1 |
| 2 | END CONN. | ASTM A351 CF8M | ASTM A216 WCB | 1 |
| 3 | BALL | ASTM A182 SS316 | ASTM A182 SS316 | 1 |
| 4 | STEM | ASTM A182 SS316 | ASTM A182 SS316 | 1 |
| 5 | SEAT | PTFE | PTFE | 2 |
| 6 | STEM SEAL | GRAPHITE | GRAPHITE | 2 |
| 7 | GLAND | SS316 | MS | 1 |
| 8 | GLAND BEARING | DELRIN | DELRIN | 1 |
| 9 | SPACER | SS316 | SS316 | 1 |
| 10 | STEM THRUST WASHER | GFT | GFT | 1 |
| 11 | BODY SEAL | GRAPHITE | GRAPHITE | 1 |
| 12 | STEM O-RING | VITON | VITON | 1 |
| 13 | END CONN. O-RING | VITON | VITON | 1 |
| 14 | STUD | ASTM A193 GR.B8M | ASTM A193 GR.B7 | 6 |
| 15 | NUT | ASTM A194 GR.8M | ASTM A194 GR.2H | 6 |
| 16 | LEVER | SS410 | SS410 | 1 |
| 17 | STOPER | MS | MS | 1 |
Contact us to get a quick quote for your requirement.
|
Nominal Diameter (mm) |
Nominal Diameter (inch) |
Kv (m3/h) |
Cv (gal/min) |
|
15 |
1/2″ |
19,4 |
22,6 |
|
20 |
3/4″ |
45,6 |
53,0 |
|
25 |
1″ |
71,5 |
83,1 |
|
32 |
1 1/4″ |
105 |
122,1 |
|
40 |
1 1/2″ |
170 |
197,7 |
|
50 |
2″ |
275 |
319,8 |
|
65 |
2 1/2″ |
507 |
589,5 |
|
80 |
3″ |
905 |
1052,3 |
|
100 |
4″ |
1414 |
1644,2 |
|
125 |
5″ |
2362 |
2746,5 |
|
150 |
6″ |
3694 |
4295,3 |
Ayten Tube Fittings is a leading supplier and Stockist of premium L Port Type Ball Valve in Addis Ababa, Ethiopia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the fittings industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
L Port Type Ball Valves are widely used in applications that require efficient and flexible fluid routing. In chemical and petrochemical plants, they control the direction of corrosive fluids between different process lines. The oil and gas industry utilizes them for diverting flow in fuel, lubricant, and gas distribution systems. In water treatment and HVAC systems, they enable easy switching between supply and return lines. These valves are also common in pharmaceutical, food processing, and power generation systems, offering precise control, quick operation, and reliable performance in both manual and automated flow control setups.
Please feel free to contact us if you need any further information or for enquiry.
