Stainless Steel 316 Hydraulic Fittings

Home > Stainless Steel > Stainless Steel 316 Hydraulic Fittings

Ayten Tube Fittings is a reputable manufacturer and supplier of top-notch Stainless Steel 316 Hydraulic Fittings based in Addis Ababa, Ethiopia. These fittings are crafted for dependable performance in high-pressure hydraulic systems. Our SS 316 hydraulic fittings are designed to offer exceptional corrosion resistance, strength, and leak-proof connections, ensuring they stand the test of time in demanding industrial settings. With a focus on precision manufacturing and rigorous quality control, Ayten Tube Fittings provides products that adhere to international safety and reliability standards. These fittings are perfect for fluid handling and hydraulic systems that need to withstand aggressive media, high temperatures, and continuous operational stress.

DIN 1.4401 Hydraulic Stainless Steel Bulkhead Union Fittings Price in Gondar, Stainless Steel S31600 Hydraulic Banjo Elbow Supplier in Dire Dawa, Stainless Steel 316 Hydraulic Female Stud Coupling Manufacturer in Addis Ababa, DIN 1.4401 Stainless Steel Hydraulic Straight Coupling in Adama, Stainless Steel UNS S31600 Hydraulic Tube Fittings Supplier in Dire Dawa, 316 Stainless Steel Hydraulic Straight Coupling in Addis Ababa, Ethiopia, Stainless Steel SUS 316 Hydraulic Male Stud Coupling Price List in Addis Ababa, X5CrNiMo17-12-2 Stainless Steel Hydraulic Male Stud Coupling Price in Adama

Made from a blend of 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, our Stainless Steel 316 Hydraulic Fittings boast remarkable resistance to corrosion, pitting, and crevice corrosion, especially in chloride-rich environments. They feature high tensile and yield strength, impressive impact toughness, and outstanding durability even under high pressure and temperature conditions. The austenitic stainless steel structure guarantees excellent dimensional stability, mechanical integrity, and resistance to oxidation. These fittings are built to perform reliably in tough industrial environments, where they may encounter aggressive fluids, high-stress hydraulic operations, and extended use.

Stainless Steel 316 Hydraulic Fittings Specifications

DESIGN STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	SS 316 ,SS 316L
MATERIAL	SS 316 ,SS 316L
SERIES	LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
CONNECTIONS	TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE
CONNECTIONS	WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL
BODY TYPE	FORGED, BAR STOCK
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	STAINLESS STEEL 316 – (-60C TO 400C)
APPLICATIONS & INDUSTRIES	CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT
MATERIAL DESIGNATOR	STAINLESS STEEL – ASTM A 276 , ASTM 182

Stainless Steel 316 Hydraulic Fittings Chemical Composition

Grade		Mn	C	S	Mo	N	Si	P	Cr	Ni
316	Minimum	–	–	–	2.00	–	–	0	16.0	10.0
316	Maximum	2.0	0.08	0.03	3.00	0.10	0.75	0.045	18.0	14.0
316H	Minimum	0.04	0.04	–	2.00	–	0	–	16.0	10.0
316H	Maximum	0.10	0.10	0.03	3.00	–	0.75	0.045	18.0	14.0

Stainless Steel 316 Hydraulic Fittings Mechanical Properties

Grade	Elong (% in 50mm) min	Yield Str 0.2% Proof (MPa) min	Tensile Str (MPa) min	Hardness
Grade	Elong (% in 50mm) min	Yield Str 0.2% Proof (MPa) min	Tensile Str (MPa) min	Rockwell B (HR B) max	Brinell (HB) max
316	40	205	515	95	217
316H	40	205	515	95	217

Stainless Steel 316 Hydraulic Fittings Equivalent

Grade	British		Euronorm		UNS No	SS	JIS
Grade	European Standards	British Standards	DIN No	Name	UNS No	SS	JIS
316	58H, 58J	316S31	1.4401	X5CrNiMo17-12-2	S31600	2347	SUS 316
316H	–	316S51	–	–	S31609	–	–

Top Stainless Steel 316 Hydraulic Fittings Manufacturing Company in Addis Ababa

At Ayten Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel 316 Hydraulic Fittings in Addis Ababa, Ethiopia. Our advanced manufacturing facilities, strategically positioned in the Ethiopia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Stainless Steel Hydraulic Fittings

SS UNS S31600 Male Stud Coupling in Addis Ababa, Stainless Steel 316 Equal Cross Hydraulic Fittings Supplier And Manufacturer in Adama, Hydraulic Stainless Steel DIN 1.4401 Swivel Fittings Manufacturer in Dire Dawa, SS SUS 316 Hydraulic Equal Elbow Fittings Manufacturer in Gondar, X5CrNiMo17-12-2 Stainless Steel Swivel Fittings Supplier in Gondar, 316 SS Equal Cross Hydraulic Fittings Supplier in Mek’ele

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Stainless Steel 316 Hydraulic Fittings in Addis Ababa, Ethiopia

Ayten Tube Fittings is a leading supplier and stockist of premium Stainless Steel 316 Hydraulic Fittings in Addis Ababa, Ethiopia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Stainless Steel 316 Hydraulic Fittings Uses

Stainless Steel 316 Hydraulic Fittings are a go-to choice in industries that need top-notch corrosion resistance and dependable high-pressure fluid transfer. You’ll find them in places like oil and gas refineries, petrochemical and chemical plants, marine and offshore operations, desalination facilities, power generation units, food and beverage processing, pharmaceuticals, and industrial automation systems. These fittings are perfect for hydraulic circuits, fluid control systems, instrumentation lines, and high-pressure pipelines that deal with corrosive or aggressive substances. SS 316 hydraulic fittings guarantee leak-proof connections, enhance operational safety, and offer a long service life, all while maintaining stable performance in tough industrial settings.
