Ayten Tube Fittings, based in Addis Ababa, Ethiopia, has earned a solid reputation as a reliable manufacturer and supplier of top-notch industrial fittings that prioritize durability, precision, and performance. One of their standout offerings, the Inconel Hydraulic Fittings, is specifically designed to provide exceptional strength and corrosion resistance, even in the toughest environments. Thanks to cutting-edge manufacturing technology and rigorous quality assurance practices, Ayten Tube Fittings guarantees that every fitting adheres to international standards. Their dedication to innovation and dependability has made them a go-to choice for various industries, including oil and gas, chemical processing, aerospace, and power generation, both in Ethiopia and around the world.
Inconel Hydraulic Fittings are crafted from high-performance nickel-chromium-based superalloys, mainly consisting of nickel, chromium, and molybdenum. This unique composition offers remarkable resistance to oxidation, corrosion, and degradation at high temperatures. These alloys boast impressive mechanical properties, such as high tensile and yield strength, fatigue resistance, and outstanding toughness. Their structural integrity under extreme pressure and temperature guarantees reliable performance in critical applications. The blend of chemical durability and mechanical strength makes Inconel Hydraulic Fittings perfect for harsh industrial settings that demand dependable and long-lasting fluid connections.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | INCONEL 625, INCONEL 718, INCONEL 825, INCOLOY 800 |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | 6 MM TO 42 MM |
| CONNECTIONS | TUBE TO MALE THREAD , TUBE TO BUTT WELD , TUBE TO FEMALE THREAD , TUBE TO SOCKET WELD , TUBE TO TUBE , TUBE TO 24* CONE, TUBE TO JIC 37* , TUBE TO ADJUSTBALE STANDPIPE , TUBE TO SWIVEL END |
| WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO 24* CONE ,WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| Inconel | Element (% By Mass) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ni | Cr | Fe | Mo | Nb | Co | Mn | Cu | Al | Ti | Si | C | S | P | B | |
| 600 | 72.0 | 14.0–17.0 | 6.0–10.0 | 1.0 | 0.5 | 0.5 | 0.15 | 0.015 | |||||||
| 617 | 44.2–56.0 | 20.0–24.0 | 3.0 | 8.0–10.0 | 10.0–15.0 | 0.5 | 0.5 | 0.8–1.5 | 0.6 | 0.5 | 0.15 | 0.015 | 0.015 | 0.006 | |
| 625 | 58.0 | 20.0–23.0 | 5.0 | 8.0–10.0 | 3.15–4.15 | 1.0 | 0.5 | 0.4 | 0.4 | 0.5 | 0.1 | 0.015 | 0.015 | ||
| 690 | 59.5 | 30 | 9.2 | 0.35 | 0.01 | 0.02 | 0.35 | 0.019 | 0.003 | ||||||
| 718 | 50.0–55.0 | 17.0–21.0 | Balance | 2.8–3.3 | 4.75–5.5 | 1.0 | 0.35 | 0.2–0.8 | 0.65–1.15 | 0.3 | 0.35 | 0.08 | 0.015 | 0.015 | 0.006 |
| X-750 | 70.0 | 14.0–17.0 | 5.0–9.0 | 0.7–1.2 | 1.0 | 1.0 | 0.5 | 0.4–1.0 | 2.25–2.75 | 0.5 | 0.08 | 0.01 | |||
| Yield Strength 0.2% Proof (MPa) min | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Brinell (HB) max | Rockwell B (HR B) max | |||
| Psi – 75,000 , MPa – 517 | Psi – 1,35,000 , MPa -930 | 42.5 | – | – |
| Grade | UNS No | Old British | Euronorm | GOST | Japanese JIS | ||
| BS | En | No | AFNOR | ||||
| Inconel 600 Pipe | N06600 | NA 13 | NiCr15Fe | 2.4816 | NC15FE11M | МНЖМц 28-2,5-1,5 | NCF 600 |
| Inconel 625 | N06625 | NA 21 | NiCr22Mo9Nb | 2.4856 | NC22DNB4M | ХН75МБТЮ | NCF 625 |
| Inconel 601 | N06601 | NA 49 | NiCr23Fe | 2.4851 | NC23FeA | XH60BT | NCF 601 |
| Incoloy 825 | N08825 | NA 16 | NiCr21Mo | 2.4858 | NFE30C20DUM | ЭП703 | NCF 825 |
Contact us to get a quick quote for your requirement.
These fittings are commonly found in hydraulic systems that function under high pressure, temperature, and corrosive conditions. They play a vital role in oil and gas exploration, chemical plants, marine systems, power generation facilities, and aerospace applications. Inconel Hydraulic Fittings ensure secure, leak-proof connections for transferring hydraulic fluids, which is crucial for safety and system efficiency. Their resistance to oxidation and corrosion allows for consistent performance in aggressive environments, including those exposed to seawater, acids, or extreme heat. Inconel Hydraulic Fittings are highly regarded for their durability and reliability in demanding applications.
Please feel free to contact us if you need any further information or for enquiry.
