Ayten Tube Fittings is a reliable manufacturer and supplier of Hastelloy Tube Fittings based in Addis Ababa, Ethiopia. We focus on creating high-performance fittings that excel in corrosive and high-pressure environments. Our Hastelloy Tube Fittings are meticulously engineered to provide outstanding resistance to both oxidizing and reducing agents, making them perfect for critical industries. Crafted from top-quality materials like Hastelloy C22, C276, and B2, these fittings guarantee exceptional mechanical strength, leak-proof performance, and a long lifespan. At Ayten Tube Fittings, we offer a diverse selection, including compression, instrumentation, and flare fittings, all designed to meet global standards for chemical processing, marine, and power generation applications.
Hastelloy Tube Fittings are primarily made up of nickel, molybdenum, and chromium, with small amounts of iron, tungsten, and cobalt added in. This unique alloy offers remarkable resistance to pitting, crevice corrosion, and stress-corrosion cracking. The mechanical properties include a tensile strength ranging from 690 to 785 MPa, a yield strength of about 275 to 355 MPa, and an elongation of up to 45%, ensuring durability even in extreme conditions. These fittings retain their strength at high temperatures, have low thermal expansion, and provide consistent dimensional stability and weldability, making them ideal for harsh chemical and marine environments.
| Hastelloy Tube Fittings specification (ASTM / ASME) | ASTM B366, ASME SB366 |
|---|---|
| Working Pressure | Up to 6,000 psi (based on severity of application) |
| Two-Ferrule Tube Fittings | Pressure Ratings : Up to 11 000 psig (760 bar) |
| Medium-Pressure, Gaugeable | Pressure Ratings: Up to 20 000 psig (1378 bar) Temperature Ratings: Up to 1000°F (537°C) |
| High-Pressure Hastelloy C276 Tube Fittings | Pressure Ratings: Up to 60 000 psig (4134 bar) Temperature Ratings: Up to 1000°F (537°C) Materials of construction: 316 Stainless Steel Tube Fittings, Alloy 2507, Inconel 625 Tube fittings |
| Hastelloy Tube Fittings Special sizes | 22mm Hastelloy C276 tube fittings 25mm Hastelloy C22 tube fittings 32mm Hastelloy B2 tube fittings 50mm Hastelloy Ferrule tube fittings |
| Hastelloy Compression Fittings End Connections | Types: NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Hastelloy C276 Tube Fittings Sizes | 1/16 to 2 in.; 2 to 50 mm 1/4, 3/8, 1/2, 9/16, 3/4 in.; 6, 10, 12 mm |
| Brand Name | Hastelloy Tube fittings |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Types | Unions, NPT, medium-pressure cone and thread adapters, male SAE/MS, reducers, port connectors, tube adapters, caps, plugs |
| Hastelloy Hydraulic Fittings Specification | Items Made from Hex – ASTM B574 ; Items made from Round Bar- ASTM B564 |
| Tube Size | 1/16”OD to 2”OD, 2mm OD to 50mm OD |
| Threads | NPT (ANSI B1.20.1), BSP, BSPT (ISO thread configurations), UNF, SAE etc. |
| PTFE Standards | ASTM D1710, ASTM D3294 |
| Hastelloy Ferrule Tube Fittings Applicable Temperature | 150-400°C |
| Hastelloy C276 Tube Fittings Packing Details |
|
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| B2 | 0.02 max | 1.0 max | 0.1 max | 0.03 max | 1.0 max | Bal | 1.0 max | 2.0 max | 26 – 30 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| Hastelloy B2 | 9.2 g/cm3 | 1370 °C (2500 ºF ) | Psi – 1,10,000 , MPa – 760 | Psi – 51000 , MPa – 350 | 40 % |
At Ayten Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hastelloy Tube Fittings in Addis Ababa, Ethiopia. Our advanced manufacturing facilities, strategically positioned in the Ethiopia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
| OD Size: 6mm to 38mm | Inch: 1/4″ to 1 1/2″ |
Contact us to get a quick quote for your requirement.
Ayten Tube Fittings is a leading supplier and stockist of premium Hastelloy Tube Fittings in Addis Ababa, Ethiopia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
Hastelloy Tube Fittings are a go-to choice in various industries like chemical processing, petrochemical plants, marine systems, and pollution control equipment. Thanks to their exceptional corrosion resistance, they’re perfect for dealing with acidic gases, chlorides, and oxidizing agents. You’ll often find them in heat exchangers, pressure vessels, instrumentation lines, and reactor systems. In sectors such as pharmaceuticals, aerospace, and pulp & paper, these fittings ensure reliable, leak-free connections even in high-pressure and high-temperature environments. Their durability and stability make Hastelloy Tube Fittings the preferred option for critical operations where precision, safety, and longevity are key to keeping systems running efficiently and reliably.
Please feel free to contact us if you need any further information or for enquiry.
