Inconel 718 Needle Valve

Home > Inconel > Inconel 718 Needle Valve

Ayten Tube Fittings, based in Addis Ababa, Ethiopia, is a well-respected manufacturer and supplier of top-notch industrial fittings and valves that are built for precision, durability, and outstanding performance. One of their standout products is the Inconel 718 Needle Valve, known for its remarkable strength and ability to withstand extreme temperatures and corrosion. Crafted with cutting-edge technology and rigorous quality control, these valves promise long-lasting reliability and safety. Ayten Tube Fittings caters to various industries, including oil and gas, petrochemical, aerospace, and power generation, offering innovative solutions that are trusted both in Ethiopia and on the international stage.

Inconel 718 Needle Valve Supplier in Addis Ababa, High Pressure Inconel 718 Needle Valve Price List in Dire Dawa, UNS N07718 Inconel 718 Flow Control Needle Valves Manufacturer in Gondar, Inconel 718 Angle Needle Valve in Adama, 1/4 Inconel 718 Needle Valve Exporter in Dire Dawa, Alloy Needle Valve Manufacturer in Mek’ele, Inconel 718 Integral Bonnet Needle Valve In Addis Ababa, Ethiopia.

The Inconel 718 Needle Valves are made from a nickel-chromium alloy that includes niobium, molybdenum, and trace amounts of titanium and aluminum. This unique blend gives them exceptional mechanical properties, such as high tensile and yield strength, excellent creep resistance, and impressive fatigue life even at elevated temperatures. The alloy’s outstanding resistance to oxidation and corrosion makes it perfect for high-pressure and high-temperature settings. Inconel 718 retains its structural integrity and hardness, even under intense stress, making these needle valves a reliable choice for precise flow control in challenging operating conditions.

Inconel 718 Needle Valve Specifications

VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, FLANGE END
FLOW PATTERN	STRAIGHT, ANGLE, CROSS PATTERNS
FUNCTION	2 WAY, 3 WAY
BODY SHAPE	SQUARE, ROUND, HEXAGON
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15,000 PSI, 20000 PSI
ORIFICE SIZE	2 MM TO 9.5 MM
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C ) RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK, FORGED
HANDLE	BAR T-HANDLE,KNOB HANDLE, WHEEL HANDLE
PACKING DETAILS	BOX PACKING, WOODEN PALLET
MATERIAL	INCONEL 718

Inconel 718 Needle Valve Chemical Composition

Ni	Cr	Fe	Mo	Nb+Ta	C	Mn	Si	Ph	S	Ti	Cu	B	Al	Co
Min	50	17	Bal	2.8	4.75	–	–	–	–	–	0.65	–	–	0.20	–
Max	55	21	–	3.3	5.50	0.08	0.035	0.35	0.015	0.015	1.15	0.30	0.0006	0.80	1.00

Inconel 718 Needle Valve Mechanical Properties

0.2% Proof Stress	Tensile Strength	Elongation	Reduction of area	Hardness
MPA	MPA	%	%	HB
Min	Min	Min	Min	Min
1034	1275	12	15	331

Top Inconel 718 Needle Valve Manufacturing Company in Addis Ababa

At Ayten Tube Fittings, we are the largest supplier, manufacturer, and exporter of Inconel 718 Needle Valve in Addis Ababa, Ethiopia. Our advanced manufacturing facilities, strategically positioned in the Ethiopia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Inconel 718 Needle Valve

Inconel 718 Needle Valve Equivalent

STANDARD	WNR Material Number	UNS	JIS	BS	GOST	AFNOR	EN
718	2.4668	N07718	–	–	–	–	–

NPT Thread Inconel 718 Needle Valve Manufacturer in Addis Ababa, Inconel 718 Flow Control Needle Valve Exporter in Dire Dawa, DIN 2.4668 Alloy Needle Valve Supplier in Gondar, Instrumentation Inconel 718 Needle Valve Supplier in Adama, Inconel 718 Flow Control Needle Valve In Gondar, Inconel 718 Needle Valve In Adama, Inconel 718 Integral Bonnet Needle Valve Price List in Mek’ele, Alloy Needle Valve Manufacturer in Addis Ababa, Inconel 718 Flow Control Needle Valve Exporter in Dire Dawa, Ethiopia.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Inconel 718 Needle Valve Supplier in Addis Ababa, Ethiopia

Ayten Tube Fittings is a leading supplier and stockist of premium Inconel 718 Needle Valve in Addis Ababa, Ethiopia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the fittings industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Inconel 718 Needle Valve Uses

These Inconel 718 Needle Valves are commonly used in industries that demand accurate flow regulation and tight shut-off capabilities under extreme temperature and pressure scenarios. They are particularly well-suited for applications in oil refineries, chemical processing plants, power generation systems, aerospace operations, and marine environments. These valves excel in high-pressure instrumentation and hydraulic systems where precision and durability are crucial. Their remarkable resistance to corrosion, oxidation, and thermal fatigue guarantees a long service life. Inconel 718 Needle Valves significantly enhance system reliability, safety, and efficiency in critical industrial applications around the globe.
